The LDG-3000 granulation line from TechnoMaszBud, based on the prime-300 pellet mill is designed for the production of pellets from 2 mm to 8 mm diameter from various types of raw materials, including sawdust, chips, dust and other waste of wood and sawdust. It is also used for making animal feed.
This line differs from the LDG-2000 model in that it has a more powerful pellet mill. The pelleting line can be used as an equipment for the production of pellet and granular feed, both at home and in business.
For your convenience we can help to choose a line to meet your requirements as well as to help you to install, start and achieve the desired result!
The line consists of:
- Screw feeder PS-200:
This unit consumes 0.75 kW of electricity and has a smooth control of the feed rate using a frequency converter.
- Hydration System:
The main components of the hydration system are: valve, pump, water tank for 200 liters, nozzle. The System is connected to a rack above the working part, allowing the required measured amount of moisture to be added during granulation. Power consumption 0,37 kW.
- Reliable PRIME-300 Pellet Mill:
The PRIME-300 Granulator can easily handle different types of raw materials with a capacity of up to 300 kg / hour for sawdust pellets and up to 700 kg / hour for feed pellets. Also for different types of raw materials will be installed different engines, for feed – 30 kW, for pellet – 22 kW.
- Calibrator-cooler for pellet / pellet KC-100:
This part serves as additional cooler for the product, as the pellets in turn heat up during pelting. This device will also remove dust and crumbs using a special drum. This node consumes 0.12 kW.
- SO-2 closed extraction system:
This device, by means of a fan, ensures the circulation of the Air necessary to cool the pellets and collect calibrated scraps of raw material and dust in the container in the form of bags mounted on it. Power – 1.5 kW.
- Control Panel:
The small dimensions and built-in automation cooling system make the control panel reliable and convenient to install near the production line. The Panel contains an ammeter and thermal protection for each engine in the line
Cables to connect the line are not part of the set
LDG-3000 is designed for the production of granulated feed and pellets. The equipment will easily process sawdust of hard and softwood trees, waste corn, straw, grass, hay, husks of seeds, waste plastics, compound feed with cereal composition.
